Bulk Milk Cooler 2000 Liters

CAPACITY: 2000 LITRES

KRISHNA/DX-/HSC

SR.NO.	DESCRIPTION	SPECIFICATION
A	REFRIGERATION UNIT
	TYPE	DIRECT EXPENSION
	MAKE OF COMPRESSOR	EMERSON COPELAND
	MODEL	MI 2
	NO. OF COMPRESSOR	TWO
	COOLING CAPACITY	7535 X 2 KCAL / HR.
	NO. OF FAN	TWO
	TYPE OF REFRIGERENT	R-22
B	MILK TANK AISI 304 SS
	RATED CAPACITY	2000 LTRS.
	GROSS CAPACITY	2200 LTRS.
	MODEL	DX – HSC
	MAKE	MAHAVIR
	MATERIAL OF CONSTRUCTION	AISI – 304
	FINISH	2 B
	TYPE OF TANK	HORIZONTAL SEMI CYLINDRICAL
	THICKNESS OF SHEET	INNER/OUTER 2.0/1.5MM
	NO. OF AGITATOR	ONE WITH 21-30 RPM
	CIP FACILITY	MANUALLY
	TYPE OF INSULATION	BY INJECTION–HIGH DENSITY 40 KG/CU.M
	THICKNESS OF INSULATION	50 MM
	EFFICIENCY OF INSULATION	AS PER ISO 5708.
	AMBIENT TEMP.	38⁰C
	MAX. COOLING TIME	3.0 HOURS
	POWER REQUIREMENT	35⁰C TO 4⁰C.
	MILK TEMP. RANGE	35° C TO 4° C
D	CONNECTED LOAD	COMPRESSOR 2 X 13.6 AMP.
		CONDENSOR FAN 1.70 AMP.
		AGITATOR 0.35 AMP.
		MILK PUMPS 6 AMP.

KRISHNA/DX-HSC

CAPACITY: 2000 LITRES

SR.NO.	ITEM	MAKE	OTHER DETAIL	QUANTITY
1.	HERMETICALLY SEALED COMPRESSOR	EMERSONCOPELAND	CR-36	2 NOS.
	CAPACITY		7535 X 2
	ELECTRIC LOAD		13.6 X 2 AMP
2.	NAME OF REFRIGERANT	R-22/404/407		8-10 KG.
3.	AGITATOR MOTOR	SIREM, FRANCE	0.35 AMP	1 NO.
	RPM OF AGITATOR		21-30 RPM
4	CONDENSING UNIT
	TYPE		AIR COOLED	2 NOS. FAN
	MATERIAL OF CONSTRUCTION		COPPER PIPE
	FAN		1.70 AMP.
5.	CONTROL PANEL
	ELECTRICAL CONTACTOR 440 V	L & T
	RELAY	L & T
	LP/HP CUTOUT	SEALED		ONE EACH
	DIGITAL TEMPERATURE INDICATOR	SUB-ZERO OR EQUIVALENT		ONE
6.	THERMOPLATE (DIMPLE SS SHEET)	IMPORTED	IMPORTED	ONE / TWO
	MATERIAL OF CONSTRUCTION		AISI 304 SS
7.	SS TANK WITH COVER	MAHAVIR	AISI 304 SS
	DIMPLE PLATE THICKNESS		2 MM/1.5 MM
8.	DIMENSION OF TANK
	RATED CAPACITY LITERS		2000 LTRS.
	GROSS CAPACITY LITERS		2200 LTRS.
	MODEL		DX-HSC
	THICKNESS INNER/OUTER		2MM / 1.5MM
9	INSULATIONS
	THICKNESS OF INSULATION		50 MM
	MATERIAL OF INSULATION		POLYURETHANE
